JJM23W-64~320P External thread pressure gauge stop valve
Purpose:
This valve is suitable for opening and closing in the pipeline with nominal pressure PN ≤ 32Mpa and working temperature ≤ 425 ℃.
Installation:
This structure can be directly connected with the corresponding instrument of the pipeline, and can also be customized with nut connecting pipe for direct welding connection and installation.
Performance parameters:
Nominal pressure (PN) | 6.4~32MPa |
Test pressure (PS) | 1.5PN |
Working medium | Gas, liquid |
Host material: | Stainless steel, molybdenum and titanium dioxide |
Main connection size:
Nominal diameterDN | L | D | W | H |
12 | 64 | M20x1.5(M14x1.5)1/2NPT | 65 | 80 |
14 | 64 | 65 | 80 | |
18 | 70 | 80 | 85 |
